Scattered Polaroids Gallery

A flat-style Polaroid gallery where the items are scattered randomly in a container. When a specific item is selected, it will move to the middle while the other Polaroids will make space for it by moving to the sides. Optionally, an item can have a backface which will be shown by flipping the Polaroid when clicking on the current navigation dot again.

ScatteredPolaroidGallery

View demo Download source

Today we’d like to share a little gallery experiment with you. We wanted to revisit the classic look of scattered Polaroids and bring it to a next, flat level with some nice effects. The resulting gallery shows some Polaroid images with a title, randomly rotated and spread in a container. When navigating the images, the current one will be moved to the center and the resting Polaroids will move to the sides. Optionally, we’ll have a backside for each Polaroid which can be viewed by clicking the current dot of the navigation again. The indication for an existing backside will be a rotated arrow on the dot. Once the dot is clicked again, the dot itself will flip and so will the Polaroid, revealing the description on the back.

We use the following structure for the gallery:

<section id="photostack-1" class="photostack photostack-start">
	<div>

		<!-- default Polaroid without backside -->
		<figure>
			<a href="http://goo.gl/Qw3ND4" class="photostack-img">
				<img src="img/1.jpg" alt="img01"/>
			</a>
			<figcaption>
				<h2 class="photostack-title">Serenity Beach</h2>
			</figcaption>
		</figure>

		<!-- Polaroid with backside -->
		<figure>
			<a href="http://goo.gl/fhwlSP" class="photostack-img">
				<img src="img/2.jpg" alt="img02"/>
			</a>
			<figcaption>
				<h2 class="photostack-title">Happy Days</h2>
				<!-- optional backside -->
				<div class="photostack-back">
					<p>Fish don't fry in the kitchen and beans don't burn on the grill. Took a whole lotta tryin' just to get up that hill. Baby if you've ever wondered - wondered whatever became of me. </p>
				</div>
			</figcaption>
		</figure>

		<!-- Example for different shuffle iteration count -->
		<figure data-shuffle-iteration="3">
			<!-- ... -->
		</figure>

		<!-- Example for a "dummy" Polaroid -->
		<figure data-dummy>
			<a href="#" class="photostack-img"><img src="img/7.jpg" alt="img07"/></a>
			<figcaption>
				<h2 class="photostack-title">Lovely Green</h2>
			</figcaption>
		</figure>

		<!-- ... -->
	</div>
</section>

The “photostack-start” class can be used to show an initial overlay on the gallery container. Once the gallery is clicked, the items will make their first move and the first item will be shown in the middle.

The div with the class “photostack-back” can be used to insert some more info for the backside of the Polaroid.

The shuffle iteration count (the amount of times we want all Polaroids to move around before the next item becomes current) can be controlled with the data-attribute data-shuffle-iteration.

The can also contain “dummy” items which will be shown in the container but which will not be part of the viewable gallery. This can be useful in cases where only a subset of a certain image collection should be shown. Imagine an article about your travels where in each section you describe a specific location. You’d set the irrelevant items as dummies and only the Polaroids that are specific to that location would be viewable in detail. In the next section you’d set the others to dummies.

Note that the main wrapping div (immediate child of the section) is set to a width and height of 100%, which means that the items will be scattered across the whole container. If we would like to compact the space of spreading, we could also set the dimension of that div to a smaller one.

Take a look at some screenshots of the gallery:

Optionally, the initial state of the gallery can have an overlay
Optionally, the initial state of the gallery can have an overlay

The current image moves to the middle and the resting items will make way and move to the sides
The current image moves to the middle and the resting items will make way and move to the sides
If there is a backside, we can flip the Polaroid by clicking on the navigation dot for a second time
If there is a backside, we can flip the Polaroid by clicking on the navigation dot for a second time

I hope you like this gallery idea and find it inspirational :)

View demo Download source

Previous:
Next:

Tagged with:

Mary Lou (Manoela Ilic) is a freelance web designer and developer with a passion for interaction design. She studied Cognitive Science and Computational Logic and has a weakness for the smell of freshly ground peppercorns.

View all contributions by

Website: http://tympanus.net/

Related Articles

Feedback 54

  1. 1

    Why is there only 6 Polaroids in the Navigation, also when i have more then 6 figures in the code!?

  2. 2

    Hi, Thanks for this great code! :)

    I was wondering.. did it use to work on chrome? I when i flip a polaroid in demo 2 or 3 it doesn’t show. Tested in other browser and they seem to work. Anyone has an idea why it doesn’t work?

    • 3

      Hi Aron, thanks for your feedback! We are looking into it; Chrome Version 37.0.2062.94 on Mac does not seem to handle the backface-visibility well here. I’ll post an update once we find out how to fix it. Thanks again and cheers, ML

    • 4

      I have found the solution. It appears, that the new version of chrome sets the z-indexes differently of transformed elements (probably to 0 or lower). I can’t confirm, but the solution is rather simple, just set the z-index of the photostack back to 1.


      .csstransformspreserve3d figure.photostack-flip .photostack-back {
      z-index: 1;
      }

      That’s it :)

  3. 6

    Hi

    This code has stopped working in Chrome (mac) since it recently updated to version 37, any ideas how to fix the issue?

  4. 7

    Hi. I love this idea and would like to use it on my website/blog! Is there any way to import this into WordPress to use instead of their gallery?

  5. 8

    Hi Is there anyway to make this responsive I am testing it locally with webmatrix but when I open it with the iphone the images just show backwards text instead of the image

  6. 9

    This gallery looks cool :)
    I have 16 images and it shows only 6 pictures.
    Is there any way to show all 16 pictures??
