Thumbnail Grid with Expanding Preview

From our monthly sponsor: Create your beautiful portfolio website with Squarespace. Start your free trial.Advertisement

If you have searched images on Google recently, you might have noticed the interesting expanding preview for a larger image when you click on a thumbnail. It’s a really nice effect and it is very practical, making a search much easier. Today we want to show you how to create a similar effect on a thumbnail grid. The idea is to open a preview when clicking on a thumbnail and to show a larger image and some other content like a title, a description and a link.

The interesting part is to calculate the correct preview height and to scroll the page to the right position. We’ll expand the preview in a way so that we can see the respective thumbnail row and cover the rest of the remaining page. Note that we don’t use very large images for the preview in the demo so you might see a lot of empty space on large monitors.

The demo features some amazing artwork by Jaime Martinez.

So let’s start!

The Markup

Initially, we need a thumbnail grid for which we will use an unordered list. Each list item will contain an anchor which will have several data attributes:

<ul id="og-grid" class="og-grid">
	<li>
		<a href="http://cargocollective.com/jaimemartinez/" data-largesrc="images/1.jpg" data-title="Azuki bean" data-description="Swiss chard pumpkin bunya nuts maize plantain aubergine napa cabbage soko coriander sweet pepper water spinach winter purslane shallot tigernut lentil beetroot.">
			<img src="images/thumbs/1.jpg" alt="img01"/>
		</a>
	</li>
	<li>
		<a href="http://cargocollective.com/jaimemartinez/" data-largesrc="images/2.jpg" data-title="Veggies sunt bona vobis" data-description="Komatsuna prairie turnip wattle seed artichoke mustard horseradish taro rutabaga ricebean carrot black-eyed pea turnip greens beetroot yarrow watercress kombu.">
			<img src="images/thumbs/2.jpg" alt="img02"/>
		</a>
	</li>
	<li><!-- ... --></li>
	<!-- ... -->
</ul>

The href value will be used to construct the link in the preview description (this also comes in handy when JavaScript is disabled). The data-largesrc attribute contains the path to the larger image. data-title and data-description contain the title and description, respectively.

When we click on a thumbnail, we want a preview element to appear under the list item. For that we will need to insert an element into the grid. In fact, we will use the list item itself and add the preview element after the anchor:

<li>

	<a href="http://cargocollective.com/jaimemartinez/" data-largesrc="images/2.jpg" data-title="Veggies sunt bona vobis" data-description="Komatsuna prairie turnip wattle seed artichoke mustard horseradish taro rutabaga ricebean carrot black-eyed pea turnip greens beetroot yarrow watercress kombu.">
		<img src="images/thumbs/2.jpg" alt="img02"/>
	</a>

	<div class="og-expander">
		<div class="og-expander-inner">
			<span class="og-close"></span>
			<div class="og-fullimg">
				<div class="og-loading"></div>
				<img src="images/2.jpg">
			</div>
			<div class="og-details">
				<h3>Veggies sunt bona vobis</h3>
				<p>Komatsuna prairie turnip wattle seed artichoke mustard horseradish taro rutabaga ricebean carrot black-eyed pea turnip greens beetroot yarrow watercress kombu.</p>
				<a href="http://cargocollective.com/jaimemartinez/">Visit website</a>
			</div>
		</div>
	</div>

</li>

Let’s style everything!

The CSS

Note that the CSS will not contain any vendor prefixes, but you will find them in the files.

So, let’s start with the thumbnail grid. It will be full width and we’ll center the text. In this case this will mean that it will center the thumbnails because we’ll set them to display: inline-block:

.og-grid {
	list-style: none;
	padding: 20px 0;
	margin: 0 auto;
	text-align: center;
	width: 100%;
}

.og-grid li {
	display: inline-block;
	margin: 10px 5px 0 5px;
	vertical-align: top;
	height: 250px;
}

The links and images will be displayed as block elements and we’ll remove some default styling:

.og-grid li > a,
.og-grid li > a img {
	border: none;
	outline: none;
	display: block;
	position: relative;
}

When we click on an item, we will give a special class to the respective list item which will be called og-expanded. We’ll add a little arrow as pseudo-element to the anchor:

.og-grid li.og-expanded > a::after {
	top: auto;
	border: solid transparent;
	content: " ";
	height: 0;
	width: 0;
	position: absolute;
	pointer-events: none;
	border-bottom-color: #ddd;
	border-width: 15px;
	left: 50%;
	margin: -20px 0 0 -15px;
}

The preview itself will have the class og-expander and we’ll position that element absolutely. The initial height of the preview will be 0 and we’ll set the overflow to hidden:

.og-expander {
	position: absolute;
	background: #ddd;
	top: auto;
	left: 0;
	width: 100%;
	margin-top: 10px;
	text-align: left;
	height: 0;
	overflow: hidden;
}

.og-expander-inner {
	padding: 50px 30px;
	height: 100%;
}

The inner division will have some paddings and a height of 100%.

The cross for closing the preview will be created using pseudo-elements, i.e. two rotated lines:

.og-close {
	position: absolute;
	width: 40px;
	height: 40px;
	top: 20px;
	right: 20px;
	cursor: pointer;
}

.og-close::before,
.og-close::after {
	content: '';
	position: absolute;
	width: 100%;
	top: 50%;
	height: 1px;
	background: #888;
	transform: rotate(45deg);
}

.og-close::after {
	transform: rotate(-45deg);
}

.og-close:hover::before,
.og-close:hover::after {
	background: #333;
}

The wrappers for the image and for the details will be 50% wide and we’ll make them float next to each other:

.og-fullimg,
.og-details {
	width: 50%;
	float: left;
	height: 100%;
	overflow: hidden;
	position: relative;
}

The details wrapper will have some padding and we’ll center the image inside of the image wrapper by setting the text-align to center and the image itself to display: inline-block. The image will also have a max-height and max-width of 100% so that it adjusts its size to the surrounding container:

.og-details {
	padding: 0 40px 0 20px;
}

.og-fullimg {
	text-align: center;
}

.og-fullimg img {
	display: inline-block;
	max-height: 100%;
	max-width: 100%;
}

Let’s style the text elements and the link:

.og-details h3 {
	font-weight: 300;
	font-size: 52px;
	padding: 40px 0 10px;
	margin-bottom: 10px;
}

.og-details p {
	font-weight: 400;
	font-size: 16px;
	line-height: 22px;
	color: #999;
}

.og-details a {
	font-weight: 700;
	font-size: 16px;
	color: #333;
	text-transform: uppercase;
	letter-spacing: 2px;
	padding: 10px 20px;
	border: 3px solid #333;
	display: inline-block;
	margin: 30px 0 0;
	outline: none;
}

.og-details a::before {
	content: '2192';
	display: inline-block;
	margin-right: 10px;
}

.og-details a:hover {
	border-color: #999;
	color: #999;
}

The loading element will be in the same container as the image and we’ll not use any images but this CSS-only technique. We’ll create a little circle and set three box shadows: one for making the circle itself look a bit smoother and two for “copying” the element. Then we create an animation that will change the background color and the box shadow colors sequentially:

.og-loading {
	width: 20px;
	height: 20px;
	border-radius: 50%;
	background: #ddd;
	box-shadow: 0 0 1px #ccc, 15px 30px 1px #ccc, -15px 30px 1px #ccc;
	position: absolute;
	top: 50%;
	left: 50%;
	margin: -25px 0 0 -25px;
	animation: loader 0.5s infinite ease-in-out both;
}

@keyframes loader {
	0% { background: #ddd; }
	33% { background: #ccc; box-shadow: 0 0 1px #ccc, 15px 30px 1px #ccc, -15px 30px 1px #ddd; }
	66% { background: #ccc; box-shadow: 0 0 1px #ccc, 15px 30px 1px #ddd, -15px 30px 1px #ccc; }
}

Last, but not least, we’ll add two media queries for adjusting the text a bit and for hiding the full image once the screen gets so small that the preview image is not really useful anymore (we’ll also not load it in the JavaScript then).


@media screen and (max-width: 830px) {

	.og-expander h3 { font-size: 32px; }
	.og-expander p { font-size: 13px; }
	.og-expander a { font-size: 12px; }

}

@media screen and (max-width: 650px) {

	.og-fullimg { display: none; }
	.og-details { float: none; width: 100%; }

}

That’s all the style. Now, let’s take a look at the JavaScript.

The JavaScript

Let’s start by caching some elements and initializing some variables:

	// list of items
var $grid = $( '#og-grid' ),
	// the items
	$items = $grid.children( 'li' ),
	// current expanded item´s index
	current = -1,
	// position (top) of the expanded item
	// used to know if the preview will expand in a different row
	previewPos = -1,
	// extra amount of pixels to scroll the window
	scrollExtra = 0,
	// extra margin when expanded (between the preview element and the next item row)
	marginExpanded = 10,
	$window = $( window ), winsize,
	$body = $( 'html, body' ),
	// transitionend events
	transEndEventNames = {
		'WebkitTransition' : 'webkitTransitionEnd',
		'MozTransition' : 'transitionend',
		'OTransition' : 'oTransitionEnd',
		'msTransition' : 'MSTransitionEnd',
		'transition' : 'transitionend'
	},
	transEndEventName = transEndEventNames[ Modernizr.prefixed( 'transition' ) ],
	// support for csstransitions
	support = Modernizr.csstransitions,
	// default settings
	settings = {
		minHeight : 500,
		speed : 350,
		easing : 'ease'
	};

We will start by preloading all the images (thumbnails) in the grid. We then save the offset top and height for each item in the grid, get the current window’s size, and initialize some events:

	function init( config ) {

		// the settings..
		settings = $.extend( true, {}, settings, config );

		// preload all images
		$grid.imagesLoaded( function() {

			// save item´s size and offset
			saveItemInfo( true );
			// get window´s size
			getWinSize();
			// initialize some events
			initEvents();

		} );

	}

	// saves the item´s offset top and height (if saveheight is true)
	function saveItemInfo( saveheight ) {
		$items.each( function() {
			var $item = $( this );
			$item.data( 'offsetTop', $item.offset().top );
			if( saveheight ) {
				$item.data( 'height', $item.height() );
			}
		} );
	}

	function getWinSize() {
		winsize = { width : $window.width(), height : $window.height() };
	}

We will bind the click event for each item (anchor) and for the close button (when the item is opened). When we click on an item, the preview with the large image source and the details will be revealed or hidden if already shown. If we click the close button (cross) on the preview then this preview will be closed too.
We are also binding the resize event for the window, where some values are reset and the preview gets closed (if opened).

	function initEvents() {

		// when clicking an item, show the preview with the item´s info and large image;
		// close the item if already expanded.
		// also close if clicking on the item´s cross
		$items.on( 'click', 'span.og-close', function() {
			hidePreview();
			return false;
		} ).children( 'a' ).on( 'click', function(e) {

			var $item = $( this ).parent();
			// check if item already opened
			current === $item.index() ? hidePreview() : showPreview( $item );
			return false;

		} );

		// on window resize get the window´s size again
		// reset some values..
		$window.on( 'debouncedresize', function() {

			scrollExtra = 0;
			previewPos = -1;
			// save item´s offset
			saveItemInfo();
			getWinSize();
			var preview = $.data( this, 'preview' );
			if( typeof preview != 'undefined' ) {
				hidePreview();
			}

		} );

	}

With the showPreview function we will basically initialize the Preview object, which in turn will expand and reveal the details and the large version of the image. If a Preview instance is already initialized then we will only update the preview with the new details (if the clicked item is in the same row as the current expanded item) or hide it and initialize / open a new one (if not in the same row).
In order to check if the items are in the same row as the current preview, we use the offset top value of the items.

	function showPreview( $item ) {

		var preview = $.data( this, 'preview' ),
			// item´s offset top
			position = $item.data( 'offsetTop' );

		scrollExtra = 0;

		// if a preview exists and previewPos is different (different row) from item´s top, then close it
		if( typeof preview != 'undefined' ) {

			// not in the same row
			if( previewPos !== position ) {
				// if position > previewPos then we need to take the current preview´s height in consideration when scrolling the window
				if( position > previewPos ) {
					scrollExtra = preview.height;
				}
				hidePreview();
			}
			// same row
			else {
				preview.update( $item );
				return false;
			}

		}

		// update previewPos
		previewPos = position;
		// initialize new preview for the clicked item
		preview = $.data( this, 'preview', new Preview( $item ) );
		// expand preview overlay
		preview.open();

	}

The Preview object will have a reference to the currently displayed item (Preview.$item), and the index of the expanded item (Preview.expandedIdx). Note that the expanded item is not necessarily the displayed item. For instance if we click on a second item that is on the same row as the one clicked before then the Preview will be “reused” and the Preview.expandedIdx will not be the index of the Preview.$item. We need to keep the reference to the expanded item so that when the Preview is closed we know which item to “collapse”.

	// the preview obj / overlay
	function Preview( $item ) {
		this.$item = $item;
		this.expandedIdx = this.$item.index();
		this.create();
		this.update();
	}

As the Preview object is initialized we create the necessary structure where the item´s details will be rendered and we append it to the item:

	create : function() {
		// create Preview structure:
		this.$title = $( '<h3></h3>' );
		this.$description = $( '<p></p>' );
		this.$href = $( '<a href="#">Visit website</a>' );
		this.$details = $( '<div class="og-details"></div>' ).append( this.$title, this.$description, this.$href );
		this.$loading = $( '<div class="og-loading"></div>' );
		this.$fullimage = $( '<div class="og-fullimg"></div>' ).append( this.$loading );
		this.$closePreview = $( '<span class="og-close"></span>' );
		this.$previewInner = $( '<div class="og-expander-inner"></div>' ).append( this.$closePreview, this.$fullimage, this.$details );
		this.$previewEl = $( '<div class="og-expander"></div>' ).append( this.$previewInner );
		// append preview element to the item
		this.$item.append( this.getEl() );
		// set the transitions for the preview and the item
		if( support ) {
			this.setTransition();
		}
	}

Then we fill the previous structure with the item´s details (stored in data attributes and the href).
The update function will also be used to just update the content of an existing preview.

	update : function( $item ) {

		// update with new item´s details
		if( $item ) {
			this.$item = $item;
		}

		// if already expanded, remove class "og-expanded" from current item and add it to new item
		if( current !== -1 ) {
			var $currentItem = $items.eq( current );
			$currentItem.removeClass( 'og-expanded' );
			this.$item.addClass( 'og-expanded' );
			// position the preview correctly
			this.positionPreview();
		}

		// update current value
		current = this.$item.index();

		// update preview´s content
		var $itemEl = this.$item.children( 'a' ),
			eldata = {
				href : $itemEl.attr( 'href' ),
				largesrc : $itemEl.data( 'largesrc' ),
				title : $itemEl.data( 'title' ),
				description : $itemEl.data( 'description' )
			};

		this.$title.html( eldata.title );
		this.$description.html( eldata.description );
		this.$href.attr( 'href', eldata.href );

		var self = this;

		// remove the current image in the preview
		if( typeof self.$largeImg != 'undefined' ) {
			self.$largeImg.remove();
		}

		// preload large image and add it to the preview
		// for smaller screens we don´t display the large image (the last media query will hide the wrapper of the image)
		if( self.$fullimage.is( ':visible' ) ) {
			this.$loading.show();
			$( '<img/>' ).load( function() {
				self.$loading.hide();
				self.$largeImg = $( this ).fadeIn( 350 );
				self.$fullimage.append( self.$largeImg );
			} ).attr( 'src', eldata.largesrc );
		}

	}

To reveal the preview we need to set the height of the Preview element and also of the item (to push down the items below). The height of the preview will be the window´s height minus the height of the grid item. To avoid cases where that height could be too small we add the option “minHeight” where we can specify the minimum height needed for the preview element.
As the preview opens we will want to scroll the window so that the preview is completely visible (and if possible, also the item).

	open : function() {

		setTimeout( $.proxy( function() {
			// set the height for the preview and the item
			this.setHeights();
			// scroll to position the preview in the right place
			this.positionPreview();
		}, this ), 25 );

	}

	setHeights : function() {

		var self = this,
			onEndFn = function() {
				if( support ) {
					self.$item.off( transEndEventName );
				}
				self.$item.addClass( 'og-expanded' );
			};

		this.calcHeight();
		this.$previewEl.css( 'height', this.height );
		this.$item.css( 'height', this.itemHeight ).on( transEndEventName, onEndFn );

		if( !support ) {
			onEndFn.call();
		}

	}

	calcHeight : function() {

		var heightPreview = winsize.height - this.$item.data( 'height' ) - marginExpanded,
			itemHeight = winsize.height;

		if( heightPreview < settings.minHeight ) {
			heightPreview = settings.minHeight;
			itemHeight = settings.minHeight + this.$item.data( 'height' ) + marginExpanded;
		}

		this.height = heightPreview;
		this.itemHeight = itemHeight;

	}

	positionPreview : function() {

		// scroll page
		// case 1 : preview height + item height fits in window´s height
		// case 2 : preview height + item height does not fit in window´s height and preview height is smaller than window´s height
		// case 3 : preview height + item height does not fit in window´s height and preview height is bigger than window´s height
		var position = this.$item.data( 'offsetTop' ),
			previewOffsetT = this.$previewEl.offset().top - scrollExtra,
			scrollVal = this.height + this.$item.data( 'height' ) + marginExpanded <= winsize.height ? position : this.height < winsize.height ? previewOffsetT - ( winsize.height - this.height ) : previewOffsetT;

		$body.animate( { scrollTop : scrollVal }, settings.speed );

	}

When closing the preview we reset the heights of the preview element and the expanded item. Once this is done, the preview element / structure gets removed from the DOM.

	close : function() {

		var self = this,
			onEndFn = function() {
				if( support ) {
					$( this ).off( transEndEventName );
				}
				self.$item.removeClass( 'og-expanded' );
				self.$previewEl.remove();
			};

		setTimeout( $.proxy( function() {

			if( typeof this.$largeImg !== 'undefined' ) {
				this.$largeImg.fadeOut( 'fast' );
			}
			this.$previewEl.css( 'height', 0 );
			// the current expanded item (might be different from this.$item)
			var $expandedItem = $items.eq( this.expandedIdx );
			$expandedItem.css( 'height', $expandedItem.data( 'height' ) ).on( transEndEventName, onEndFn );

			if( !support ) {
				onEndFn.call();
			}

		}, this ), 25 );

		return false;

	}

And that's it! We hope you enjoyed this tutorial and find it inspiring!

Tagged with:

ML is a freelance web designer and developer with a passion for interaction design. She studied Cognitive Science and Computational Logic and has a weakness for the smell of freshly ground peppercorns.

http://www.codrops.com

Receive our bi-weekly Collective or official newsletter right in your inbox.

CSS Reference

Learn about all important CSS properties from the basics with our extensive and easy-to-read CSS Reference.

It doesn't matter if you are a beginner or intermediate, start learning CSS now.

Feedback 477

Comments are closed.
  1. I really love this amazing webside! Thanks so much Mary Lou! I´m creating a webside for students using some plugins from this webside. THANKS THANKS THANKS FROM SPAIN! 😉

  2. Why do you guys choose to ignore Internet Explorer 9 and below? It still holds a significant market share and makes all the cool stuff you guys built unusable in a standard deployment.

    • I think it goes the other way…
      Internet Explorer ignore what developers require nowadays, and make everything possible to complicate us.

      People should stop using IE.

  3. Hello Mary Lou, Goodbye heart, Sweet Mary Lou, I’m so in love with you! 🙂
    Great article, i was looking to build it myself, but you beat me to it. Also, it would be nice to have a Themeforest style Screenshot preview, does someone know for a good tutorial on that?

  4. Hi, thanks a ton Mary Lou…always great to visit this site. Nice tutorial n share..!

  5. Great tutorial…I’d like to use it in a website but before I need to find a fix for IE8-IE9 white space remaining after closing a detail. Does anyone find a solution?
    Thanks in advance,
    Marco

  6. Nice tutorial. On the other hand its pretty useless if it does not have IE support, since that browser is used by the majority of people.

    So, anyone have a IE fix for this?

    • Nice!

      I notice on yours when you resize the window, the enlarged image stays up, unlike on this one. Any pointers on how to change this one to do that too?

    • I love Codrop’s tutorials, but I have to say that your demo fits my purposes better as it allows for easier customization of the expanded window. Great job!

  7. Can someone provide IE8 fix. I am not a developer and I want to use this for my photography hobby.
    Much appreciate your help. thanks

  8. I’ve found the fix to the IE problem with the “X” being a “-” when the image is enlarged.

    Add these two lines to – Component.css in the og-close::before,after

    -ms-transform: rotate(45deg); /* Internet Explorer */
    -o-transform: rotate(45deg); /* Opera */

    And similary, these two to og-close::after

    -ms-transform: rotate(-45deg); /* Internet Explorer */
    -o-transform: rotate(-45deg); /* Opera */

  9. Although IE support can be important, I have read more than one comment here saying that without these plugins are useless, and suggesting that the majority of web users are using IE. This isn’t true, according to W3’s latest figures google chrome has the majority of users with almost 30%
    in fact only about 8% of people still use IE8. Added to this if you make some reasonable assumptions about these users you can conclude that they probably aren’t the sort of people that are going to be wanting to view your flashy new portfolios.

    You don’t need full browser support for IE8 and below, what you should aim for is good degradation in these older browsers so that your website will still work, and look alright, even if it doesn’t have 100% of it’s features.

    Sorry that came off as a bit of a rant, just my 2 pence

  10. The main idea is quite nice,
    but I would rather see a sleek album-slideshow than what you guys call a “full-img”.
    isn’t work so well on iPad.

  11. Does anyone know how to add a line break to the text in the expanded view?
    (In the data-description=”” element)

    • I tried using the html for line break – ” ” – inside the ‘data-description’ and this worked fine for me.

  12. Since the launch of new iTunes which pioneered this effect and later Google Image search, I was really inspired by it and trying to implement it myself, I was not even getting close to it. Thanks for sharing and making life easier. This made my day. 🙂

  13. Hi, the full images seems to load too slow from normal. Is there something wrong or no?, if there is can someone tell me how to increase the loading time of the images. ( and yes my images are only 100kb less )
